Alloy /Carbon Steel Cast Conveyor Chain for Paper Roll
Alloy /Carbon Steel Cast Conveyor Chain for Paper Roll
- Model: 63PF
wk1358@dongchuan.cn
Introduction
Conveyor Chain for Paper Roll
This series of conveyor chain is frequently utilized in papermaking industry for paper roll conveying applications.
Its top plates are welded onto the chain. In order to ensure welding quality and a flat surface created by the top plates, we adopt multi-station automatic welding machine to perform synchronous welding to multiple welding spots. Thus, the deformation caused by regional welding is minimized. Meanwhile, the top plates are cold drawn so that smooth finish and surface evenness are guaranteed.
Our paper roll conveyor chain comes with extended service life due to the following designs. Firstly, it is designed with additional SF1 shaft sleeves between the pin and the bushing. Secondly, at the both ends of pins, there are specialized bearings with arc shaped outer ring.
Specification
Chain no. | Pitch P (mm) | Inner width of inner link b1 (mm) | Diameter of roller d1 (mm) | Diameter of pin d2 (mm) | Central distance between two links L (mm) | Thickness of sidebar t (mm) | Height of top plate h1 (mm) | Length of top plate m (mm) | Tensile strength q (KN) |
| 63PF | 63 | 24 | 42 | 14 | 179 | 5 | 34.5 | 250 | 160 |
Technical Specifications
| Chain no. | Pitch P (mm) | Inner width of inner link b1 (mm) | Diameter of roller d1 (mm) | Diameter of pin d2 (mm) | Length of pin b2 (mm) | Thickness of sidebar t (mm) | Height of top plate h1 (mm) | Length of top plate m (mm) | Tensile strength q (KN) |
| 63PF2 | 63 | 130 | 30 | 20 | 213 | 6 | 50 | 220 | 176 |
